Model Name |
AMG-10IPZL01T1 |
|
Screen Size |
10.4" |
|
Active Display Area (mm) |
211.2(H)x158.4(V) |
|
Pixel Pitch (mm) |
0.20625(H)x0.20625(V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
262K/16.7M |
|
Contrast Ratio |
1024x768 |
|
Display Color |
900:1 |
|
Brightness (CD/㎡) |
1000nits(Light Sensor) |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
150(H);150(V |
|
Response Time(Typ.Tr+Tf) |
16ms |
|
Signal Connector |
VGA/DVI/USB |
|
Power Consumption |
DC 12V 4A |
|
Dimension(VxHxT) |
242.6x188.6x45.8 |
|
Operating Temperature |
-20～70℃ |
|
Storage Temperature |
-30～80℃ |
|
Relative Humidity |
5(%RH)～90(%RH) |
