Model Name |
AMG-07IPLV01T1 |
|
Screen Size |
7" |
|
Active Display Area(mm) |
153.6(H)x90(V) |
|
Pixel Pitch(mm) |
0.150(H)x0.150(V) |
|
Display Mode |
Normally white |
|
Display Color |
16.2M |
|
Display Resolution(pixel) |
1024x600 |
|
Contrast Ratio |
700:1 |
|
Brightness |
600nits |
|
Backlight |
LED |
|
Viewing Angles(CR=10) |
160(H);130(V) |
|
Response Time(Typ.Tr+Tf) |
25ms |
|
Touch Screen |
Optional |
|
Camera |
Support |
|
Motion Sensor |
Support |
|
Signal Connector |
VGA/DVI-D/HDMI/Audio |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT)mm |
212x180x63 |
|
Operating Temperature |
-20~60℃ |
|
Storage Temperature |
-30~70℃ |
|
Relative Humidity |
5[%RH]~90[%RH] |
